SS9014BTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole NPN Single Bipolar (BJT) Transistor 100 @ 1mA 5V 50nA ICBO 450mW 270MHz
PDF
/
Inventory: 1961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 60
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 50V
Collector Emitter Saturation Voltage 140mV
Collector Emitter Breakdown Voltage 45V
Vce Saturation (Max) @ Ib, Ic 300mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 50nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 1mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 45V
Transistor Type NPN
Gain Bandwidth Product 270MHz
Power Dissipation 450mW
Element Configuration Single
Number of Elements 1
Base Part Number SS9014
Frequency 270MHz
Current Rating 100mA
Max Power Dissipation 450mW
Voltage - Rated DC 45V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Box (TB)
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
