PN2222TFR
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Through Hole NPN Single Bipolar (BJT) Transistor 100 @ 150mA 10V 10nA ICBO 625mW 300MHz
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 1293
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 240mg
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2010
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 30V
Max Power Dissipation 625mW
Current Rating 600mA
Frequency 300MHz
Base Part Number PN2222
Number of Elements 1
Element Configuration Single
Power Dissipation 625mW
Gain Bandwidth Product 300MHz
Transistor Type NPN
Collector Emitter Voltage (VCEO) 30V
Max Collector Current 600mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 10V
Current - Collector Cutoff (Max) 10nA ICBO
Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 500mA
Collector Emitter Breakdown Voltage 30V
Collector Emitter Saturation Voltage 1V
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 5V
hFE Min 100
Dimensions
Height 4.58mm
Length 4.58mm
Width 3.86mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
