NZT749
RoHS
/
Package TO-261-4, TO-261AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP SINGLE Bipolar (BJT) Transistor 80 @ 1A 2V 4A 1.2W 75MHz
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
Inventory: 1149
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Surface Mount YES
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Position DUAL
Terminal Form GULL WING
Reach Compliance Code compliant
JESD-30 Code R-PDSO-G4
Number of Elements 1
Configuration SINGLE
Case Connection COLLECTOR
Power - Max 1.2W
Transistor Application SWITCHING
Polarity/Channel Type PNP
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 80 @ 1A 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 300mV @ 100mA, 1A
Voltage - Collector Emitter Breakdown (Max) 25V
Current - Collector (Ic) (Max) 4A
Transition Frequency 75MHz
Frequency - Transition 75MHz
