NST846BF3T5G
RoHS
RoHS compliant
RoHS compliantPackage SOT-1123
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 65V 0.1A SOT-1123
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.14256
≥100 USD $0.071896
≥500 USD $0.058696
≥1000 USD $0.043542
≥3000 USD $0.036634
Inventory: 1138
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mounting Type Surface Mount
Package / Case SOT-1123
Surface Mount YES
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Transistors
Max Power Dissipation 347mW
Terminal Position DUAL
Terminal Form FLAT
Frequency 100MHz
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 347mW
Power - Max 290mW
Transistor Application AMPLIFIER
Gain Bandwidth Product 100MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 65V
Max Collector Current 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 2mA 5V
Current - Collector Cutoff (Max) 15nA ICBO
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Collector Emitter Breakdown Voltage 65V
Transition Frequency 100MHz
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 6V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
