MPSA64G
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP DARL 30V 0.5A TO92
PDF
/
Inventory: 3451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Continuous Collector Current -500mA
Emitter Base Voltage (VEBO) 10V
Collector Base Voltage (VCBO) 30V
Frequency - Transition 125MHz
Collector Emitter Saturation Voltage 1.5V
Transition Frequency 125MHz
Collector Emitter Breakdown Voltage 30V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 100μA, 100mA
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 20000 @ 100mA 5V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 30V
Transistor Type PNP - Darlington
Transistor Application SWITCHING
Power Dissipation 625mW
Element Configuration Single
Polarity PNP
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number MPSA64
Time@Peak Reflow Temperature-Max (s) 40
Current Rating -500mA
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC -30V
Subcategory Other Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2005
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 4 days ago)
