MPSA55RLRAG
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 60V 0.5A TO92
PDF
/
Buying Options
Total Price: USD $1.7
Unit Price: USD $1.69765
≥1 USD $1.69765
≥10 USD $1.39365
≥100 USD $1.34995
≥500 USD $1.30625
≥1000 USD $1.26255
Inventory: 1131
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 6.35mm
Length 6.35mm
Height 6.35mm
Technical
hFE Min 100
Emitter Base Voltage (VEBO) 4V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 60V
Collector Emitter Saturation Voltage 250mV
Transition Frequency 50MHz
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 250mV @ 10mA, 100mA
Current - Collector Cutoff (Max) 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 1V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 60V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 50MHz
Transistor Application AMPLIFIER
Power Dissipation 625mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number MPSA55
Time@Peak Reflow Temperature-Max (s) 40
Frequency 50MHz
Current Rating -500mA
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC -60V
Subcategory Other Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2007
Packaging Cut Tape (CT)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 13 hours ago)
