MPSA44G
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 400V 0.3A TO-92
PDF
/
Buying Options
Total Price: USD $4.37
Unit Price: USD $4.3681
≥1 USD $4.3681
≥10 USD $3.58435
≥100 USD $3.47225
≥500 USD $3.36015
≥1000 USD $3.24805
Inventory: 1082
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 4.191mm
Length 5.1816mm
Height 5.334mm
Technical
hFE Min 40
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 500V
Collector Emitter Saturation Voltage 750mV
Transition Frequency 20MHz
Collector Emitter Breakdown Voltage 400V
Vce Saturation (Max) @ Ib, Ic 750mV @ 5mA, 50mA
Current - Collector Cutoff (Max) 500nA
DC Current Gain (hFE) (Min) @ Ic, Vce 50 @ 10mA 10V
Max Collector Current 300mA
Collector Emitter Voltage (VCEO) 400V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power Dissipation 625mW
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number MPSA44
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 300mA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC 400V
Subcategory Other Transistors
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2006
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
