MPSA27
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN - Darlington Single Bipolar (BJT) Transistor 10000 @ 100mA 5V 500mA 625mW 125MHz
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 1139
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Weight 201mg
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2006
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Transistors
Voltage - Rated DC 60V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 800mA
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MPSA27
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 625mW
Transistor Application AMPLIFIER
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 10000 @ 100mA 5V
Current - Collector Cutoff (Max) 500nA
Vce Saturation (Max) @ Ib, Ic 1.5V @ 100μA, 100mA
Collector Emitter Breakdown Voltage 60V
Transition Frequency 125MHz
Collector Emitter Saturation Voltage 1.5V
Max Breakdown Voltage 60V
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 10V
hFE Min 10000
Continuous Collector Current 500mA
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
