MPSA05 image
Favorite
MPSA05 image
Favorite
RoHS
/
Package TO-92-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description Bulk Through Hole Single 1 Bipolar (BJT) Transistor 500mA 625mW 100MHz 60V
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.05415
≥1 USD $0.05415
≥10 USD $0.04465
≥100 USD $0.04275
≥500 USD $0.0418
≥1000 USD $0.04085
Inventory: 1631
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status OBSOLETE (Last Updated: 3 days ago)

Physical

Mount Through Hole
Package / Case TO-92-3
Number of Pins 3
Weight 201mg

Technical

Packaging Bulk
Published 2005
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC 60V
Current Rating 500mA
Frequency 100MHz
Number of Elements 1
Polarity NPN
Power Dissipation-Max 625mW
Element Configuration Single
Power Dissipation 625mW
Gain Bandwidth Product 100MHz
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 500mA
Collector Emitter Breakdown Voltage 60V
Collector Emitter Saturation Voltage 250mV
Frequency - Transition 100MHz
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 4V
hFE Min 100

Dimensions

Height 6.35mm
Length 6.35mm
Width 6.35mm

Compliance

RoHS Status RoHS Compliant
Lead Free Contains Lead
