MPS6652RLRPG
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 40V 1A TO-92
PDF
/
Inventory: 2062
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Box (TB)
Published 2006
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
HTS Code 8541.21.00.95
Subcategory Other Transistors
Voltage - Rated DC -40V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Current Rating -1A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MPS6652
Pin Count 3
JESD-30 Code O-PBCY-T3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Power - Max 625mW
Transistor Application AMPLIFIER
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 600mV
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 50 @ 500mA 1V
Current - Collector Cutoff (Max) 100nA
Vce Saturation (Max) @ Ib, Ic 600mV @ 100mA, 1A
Collector Emitter Breakdown Voltage 40V
Transition Frequency 100MHz
Frequency - Transition 100MHz
Turn Off Time-Max (toff) 300ns
Turn On Time-Max (ton) 55ns
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
