MMBT3904LT1G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 40V 0.2A SOT23
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.014605
≥1 USD $0.014605
≥10 USD $0.011391
≥100 USD $0.009964
≥500 USD $0.008892
≥1000 USD $0.008464
≥10000 USD $0.008178
Inventory: 53590
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.3mm
Length 2.9mm
Height 1.11mm
Technical
Turn On Time-Max (ton) 70 ns
Turn Off Time-Max (toff) 250 ns
Max Junction Temperature (Tj) 150°C
hFE Min 100
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 40V
Collector Emitter Saturation Voltage 200mV
Transition Frequency 300MHz
Collector Emitter Breakdown Voltage 40V
Vce Saturation (Max) @ Ib, Ic 300mV @ 5mA, 50mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 10mA 1V
Max Collector Current 200mA
Collector Emitter Voltage (VCEO) 40V
Transistor Type NPN
Gain Bandwidth Product 300MHz
Power Dissipation 225mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number MMBT3904
Time@Peak Reflow Temperature-Max (s) 40
Frequency 300MHz
Current Rating 200mA
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 300mW
Voltage - Rated DC 40V
Subcategory Other Transistors
Type General Purpose
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 10 Weeks
