MMBT2369LT3G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
ON Semi MMBT2369LT3G NPN Bipolar Transistor; 0.2 A; 15 V; 3-Pin SOT-23
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.020679
≥1 USD $0.020679
≥200 USD $0.008003
≥500 USD $0.007722
≥1000 USD $0.007582
Inventory: 1089
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2.64mm
Length 3.04mm
Height 1.11mm
Technical
hFE Min 40
Emitter Base Voltage (VEBO) 4.5V
Collector Base Voltage (VCBO) 40V
Collector Emitter Saturation Voltage 250mV
Max Frequency 1MHz
Collector Emitter Breakdown Voltage 15V
Vce Saturation (Max) @ Ib, Ic 250mV @ 1mA, 10mA
Current - Collector Cutoff (Max) 400nA
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 10mA 350mV
Max Collector Current 200mA
Collector Emitter Voltage (VCEO) 15V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power Dissipation 300mW
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number MMBT2369
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 225mW
Subcategory Other Transistors
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 2 Weeks
