MMBT2369A
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN SINGLE Bipolar (BJT) Transistor 40 @ 10mA 1V 200mA 225mW 500MHz
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
≥10000 USD $2.14795
Inventory: 19748
Minimum: 1
-
+
Technical Details
Technical
Turn On Time-Max (ton) 12ns
Turn Off Time-Max (toff) 18ns
Power Dissipation-Max (Abs) 0.35W
Transition Frequency 500MHz
Current - Collector (Ic) (Max) 200mA
Voltage - Collector Emitter Breakdown (Max) 15V
Vce Saturation (Max) @ Ib, Ic 500mV @ 10mA, 100mA
JEDEC-95 Code TO-236AB
Current - Collector Cutoff (Max) 400nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 10mA 1V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power - Max 225mW
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G3
Base Part Number MMBT2369
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Transistors
HTS Code 8541.21.00.95
Additional Feature HIGH SPEED SATURATED SWITCHING
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 39 Weeks
