KST55MTF
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT PNP 60V 0.5A 3-Pin SOT-23 T/R
PDF
/
Buying Options
Total Price: USD $8.9
Unit Price: USD $8.90435
≥1 USD $8.90435
≥10 USD $7.30645
≥100 USD $7.07845
≥500 USD $6.8495
≥1000 USD $6.6215
Inventory: 1071
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 2 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Weight 30mg
Transistor Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Subcategory Other Transistors
Voltage - Rated DC -60V
Max Power Dissipation 350mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Current Rating -500mA
Frequency 50MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number KST55
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Power Dissipation 350mW
Transistor Application AMPLIFIER
Gain Bandwidth Product 50MHz
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 50 @ 100mA 1V
Current - Collector Cutoff (Max) 100nA
Vce Saturation (Max) @ Ib, Ic 250mV @ 10mA, 100mA
Collector Emitter Breakdown Voltage 60V
Transition Frequency 50MHz
Collector Emitter Saturation Voltage -250mV
Max Breakdown Voltage 60V
Collector Base Voltage (VCBO) -60V
Emitter Base Voltage (VEBO) -4V
hFE Min 50
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
