KSP8599CTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole PNP Single Bipolar (BJT) Transistor 100 @ 1mA 5V 500mA 625mW 150MHz
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.067787
≥1 USD $0.067787
≥10 USD $0.063947
≥100 USD $0.060331
≥500 USD $0.056913
≥1000 USD $0.053695
Inventory: 1126
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 100
Emitter Base Voltage (VEBO) -5V
Collector Base Voltage (VCBO) -60V
Frequency - Transition 150MHz
Current - Collector (Ic) (Max) 500mA
Voltage - Collector Emitter Breakdown (Max) 80V
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 400mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 1mA 5V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 400mV
Transistor Type PNP
Gain Bandwidth Product 150MHz
Power - Max 625mW
Power Dissipation 625mW
Element Configuration Single
Polarity PNP
Number of Elements 1
Base Part Number KSP8599
Frequency 150MHz
Current Rating -500mA
Max Power Dissipation 625mW
Voltage - Rated DC -80V
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Box (TB)
Operating Temperature 150°C TJ
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
