KSH112GTM_NB82051

ON Semiconductor
RoHS
/
Package TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description Tape & Reel (TR) Surface Mount NPN - Darlington KSH112 Bipolar (BJT) Transistor 1000 @ 2A 3V 2A 1.75W 25MHz
PDF
/
Inventory: 8180
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Frequency - Transition 25MHz
Current - Collector (Ic) (Max) 2A
Voltage - Collector Emitter Breakdown (Max) 100V
Vce Saturation (Max) @ Ib, Ic 3V @ 40mA, 4A
Current - Collector Cutoff (Max) 20μA
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 2A 3V
Transistor Type NPN - Darlington
Power - Max 1.75W
Base Part Number KSH112
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ

Physical

Supplier Device Package D-Pak
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
