KSD5041PBU
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 20V 5A TO-92
PDF
/
Inventory: 8546
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package TO-92-3
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number KSD5041
Power - Max 750mW
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 500mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 1V @ 100mA, 3A
Voltage - Collector Emitter Breakdown (Max) 20V
Current - Collector (Ic) (Max) 5A
Frequency - Transition 150MHz
