KSC3265OMTF
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 100 @ 100mA 1V 100nA ICBO 200mW 120MHz
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.044
≥1 USD $0.044
Inventory: 1435
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Weight 30mg
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 25V
Max Power Dissipation 200mW
Current Rating 800mA
Frequency 120MHz
Base Part Number KSC3265
Number of Elements 1
Element Configuration Single
Power Dissipation 200mW
Gain Bandwidth Product 120MHz
Transistor Type NPN
Collector Emitter Voltage (VCEO) 25V
Max Collector Current 800mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 1V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 400mV @ 20mA, 500mA
Collector Emitter Breakdown Voltage 25V
Collector Emitter Saturation Voltage 400mV
Collector Base Voltage (VCBO) 30V
Emitter Base Voltage (VEBO) 5V
hFE Min 100
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
