KSC2383OBU
RoHS
/
Package TO-226-3, TO-92-3 Long Body
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 160V 1A TO-92L
PDF
/
Inventory: 1659
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 60
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 160V
Frequency - Transition 100MHz
Collector Emitter Saturation Voltage 1.5V
Current - Collector (Ic) (Max) 1A
Voltage - Collector Emitter Breakdown (Max) 160V
Collector Emitter Breakdown Voltage 160V
Vce Saturation (Max) @ Ib, Ic 1.5V @ 50mA, 500mA
Current - Collector Cutoff (Max) 1μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 200mA 5V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 160V
Transistor Type NPN
Gain Bandwidth Product 100MHz
Power - Max 900mW
Power Dissipation 900mW
Element Configuration Single
Polarity NPN
Number of Elements 1
Base Part Number KSC2383
Frequency 100MHz
Current Rating 1A
Max Power Dissipation 900mW
Voltage - Rated DC 160V
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Weight 185mg
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 Long Body
Mounting Type Through Hole
Mount Through Hole
