KSA992PTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole PNP Single Bipolar (BJT) Transistor 200 @ 1mA 6V 1muA 500mW 100MHz
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.83575
≥1 USD $2.83575
≥10 USD $2.32655
≥100 USD $2.25435
≥500 USD $2.1812
≥1000 USD $2.109
Inventory: 31003
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Technical
Operating Temperature 150°C TJ
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -120V
Max Power Dissipation 500mW
Current Rating -50mA
Frequency 100MHz
Base Part Number KSA992
Number of Elements 1
Element Configuration Single
Power Dissipation 500mW
Gain Bandwidth Product 100MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) 300mV
Max Collector Current 50mA
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 1mA 6V
Current - Collector Cutoff (Max) 1μA
Vce Saturation (Max) @ Ib, Ic 300mV @ 1mA, 10mA
Collector Emitter Breakdown Voltage 120V
Collector Emitter Saturation Voltage -90mV
Collector Base Voltage (VCBO) -120V
Emitter Base Voltage (VEBO) -5V
hFE Min 200
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
