KSA642GBU
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 200 @ 50mA 1V 300mA 400mW 30V
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.183089
≥1 USD $0.183089
≥10 USD $0.172726
≥100 USD $0.162948
≥500 USD $0.153725
≥1000 USD $0.145025
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
hFE Min 70
Emitter Base Voltage (VEBO) -5V
Collector Base Voltage (VCBO) 30V
Collector Emitter Saturation Voltage -350mV
Current - Collector (Ic) (Max) 300mA
Voltage - Collector Emitter Breakdown (Max) 25V
Collector Emitter Breakdown Voltage 25V
Vce Saturation (Max) @ Ib, Ic 600mV @ 30mA, 300mA
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 50mA 1V
Max Collector Current 300mA
Collector Emitter Voltage (VCEO) 25V
Transistor Type PNP
Power - Max 400mW
Power Dissipation 400mW
Element Configuration Single
Polarity PNP
Number of Elements 1
Base Part Number KSA642
Current Rating -300mA
Max Power Dissipation 400mW
Voltage - Rated DC -25V
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
