KSA1175YBU
RoHS
/
Package TO-226-3, TO-92-3 Short Body
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 120 @ 1mA 6V 150mA 250mW 180MHz
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 10029
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 Short Body
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -50V
Max Power Dissipation 250mW
Current Rating -150mA
Base Part Number KSA1175
Element Configuration Single
Gain Bandwidth Product 180MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) 300mV
Max Collector Current 150mA
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 1mA 6V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 300mV @ 10mA, 100mA
Collector Emitter Breakdown Voltage 50V
Current - Collector (Ic) (Max) 150mA
Collector Base Voltage (VCBO) -60V
Emitter Base Voltage (VEBO) -5V
hFE Min 40
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
