CPH3216-TL-E
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistor, (-)50V, (-)1A, Low VCE(sat), (PNP)NPN Single CPH3
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.35728
≥100 USD $0.214544
≥500 USD $0.198651
≥1000 USD $0.13508
Inventory: 1108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.6mm
Length 2.9mm
Height 900μm
Technical
hFE Min 200
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 80V
Max Breakdown Voltage 50V
Collector Emitter Saturation Voltage 130mV
Transition Frequency 420MHz
Max Frequency 1MHz
Collector Emitter Breakdown Voltage 50V
Vce Saturation (Max) @ Ib, Ic 190mV @ 10mA, 500mA
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 100mA 2V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 50V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 420MHz
Transistor Application SWITCHING
Element Configuration Single
Number of Elements 1
Pin Count 3
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 900mW
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e6
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 10 Weeks
