BSR14_D87Z
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 40V 0.8A SOT-23
PDF
/
Inventory: 1766
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number BSR14
Power - Max 350mW
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 10V
Current - Collector Cutoff (Max) 10nA ICBO
Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 500mA
Voltage - Collector Emitter Breakdown (Max) 40V
Current - Collector (Ic) (Max) 800mA
Frequency - Transition 300MHz
