BCX71JLT1G
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP Single Bipolar (BJT) Transistor 250 @ 2mA 5V 20nA 350mW 800ns
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2109
≥1 USD $0.2109
≥10 USD $0.1729
≥100 USD $0.16815
≥500 USD $0.16245
≥1000 USD $0.15675
Inventory: 14257
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 day ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Transistor Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2009
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Subcategory Other Transistors
Voltage - Rated DC -45V
Max Power Dissipation 350mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating -100mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number BCX71
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Power Dissipation 350mW
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 45V
Max Collector Current 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 250 @ 2mA 5V
Current - Collector Cutoff (Max) 20nA
Vce Saturation (Max) @ Ib, Ic 550mV @ 1.25mA, 50mA
Collector Emitter Breakdown Voltage 45V
Collector Emitter Saturation Voltage -550mV
Max Breakdown Voltage 45V
Collector Base Voltage (VCBO) 45V
Emitter Base Voltage (VEBO) 5V
hFE Min 40
Turn Off Time-Max (toff) 800ns
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
