BCX71G
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount PNP BCX71 Bipolar (BJT) Transistor 120 @ 2mA 5V 100mA 350mW 45V
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.0361
≥1 USD $0.0361
≥10 USD $0.0304
≥100 USD $0.02945
≥500 USD $0.0285
≥1000 USD $0.02755
Inventory: 189704
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Current - Collector (Ic) (Max) 100mA
Voltage - Collector Emitter Breakdown (Max) 45V
Vce Saturation (Max) @ Ib, Ic 550mV @ 1.25mA, 50mA
Current - Collector Cutoff (Max) 20nA
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 2mA 5V
Transistor Type PNP
Power - Max 350mW
Base Part Number BCX71
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating -100mA
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Rated DC -45V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
