BC639
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 40 @ 150mA 2V 100nA ICBO 625mW 100MHz
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0285
≥1 USD $0.0285
≥10 USD $0.0228
≥100 USD $0.0228
≥500 USD $0.02185
≥1000 USD $0.0209
≥10000 USD $0.019
Inventory: 9419
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Contact Plating Copper, Silver, Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Weight 201mg
Transistor Element Material SILICON
Manufacturer Package Identifier TO?92 CASE 29 STYLE 14
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2002
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Through Hole
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Transistors
Voltage - Rated DC 80V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 1A
Frequency 100MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number BC639
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Power Dissipation 1W
Gain Bandwidth Product 200MHz
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 150mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 80V
Transition Frequency 200MHz
Collector Emitter Saturation Voltage 500mV
Max Breakdown Voltage 80V
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 5V
hFE Min 40
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
