BC557CZL1
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole PNP Single Bipolar (BJT) Transistor 420 @ 2mA 5V -100mA 625mW 320MHz
PDF
/
Buying Options
Total Price: USD $0.06
Unit Price: USD $0.062531
≥1 USD $0.062531
≥10 USD $0.058993
≥100 USD $0.055655
≥500 USD $0.052506
≥1000 USD $0.049533
Inventory: 1093
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Box (TB)
Published 2005
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature EUROPEAN PART NUMBER
HTS Code 8541.21.00.75
Subcategory Other Transistors
Voltage - Rated DC -45V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating -100mA
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number BC557
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Transistor Application AMPLIFIER
Gain Bandwidth Product 320MHz
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 650mV
Max Collector Current 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 420 @ 2mA 5V
Current - Collector Cutoff (Max) 100nA
Vce Saturation (Max) @ Ib, Ic 650mV @ 5mA, 100mA
Collector Emitter Breakdown Voltage 45V
Current - Collector (Ic) (Max) 100mA
Transition Frequency 320MHz
Collector Emitter Saturation Voltage -300mV
Collector Base Voltage (VCBO) -50V
Emitter Base Voltage (VEBO) 5V
hFE Min 420
Continuous Collector Current -100mA
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
