BC547_J22Z
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN BC547 Bipolar (BJT) Transistor 110 @ 2mA 5V 100mA 500mW 300MHz
PDF
/
Inventory: 2767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number BC547
Power - Max 500mW
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 110 @ 2mA 5V
Current - Collector Cutoff (Max) 15nA ICBO
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Voltage - Collector Emitter Breakdown (Max) 45V
Current - Collector (Ic) (Max) 100mA
Frequency - Transition 300MHz
