BC32716BU
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 100 @ 100mA 1V 100nA 625mW 100MHz
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.044
≥1 USD $0.044
Inventory: 16341
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 3.86mm
Length 4.58mm
Height 4.58mm
Technical
hFE Min 100
Emitter Base Voltage (VEBO) -5V
Collector Base Voltage (VCBO) -10V
Collector Emitter Saturation Voltage -700mV
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 45V
Vce Saturation (Max) @ Ib, Ic 700mV @ 50mA, 500mA
Current - Collector Cutoff (Max) 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 1V
Max Collector Current 800mA
Collector Emitter Voltage (VCEO) 45V
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 100MHz
Transistor Application SWITCHING
Power Dissipation 625mW
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Base Part Number BC327
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 100MHz
Current Rating -800mA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC -45V
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 179mg
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Factory Lead Time 7 Weeks
