BC308A_J35Z
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP BC308 Bipolar (BJT) Transistor 120 @ 2mA 5V 100mA 500mW 130MHz
PDF
/
Inventory: 8004
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Supplier Device Package TO-92-3
Technical
Operating Temperature 150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number BC308
Power - Max 500mW
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 2mA 5V
Current - Collector Cutoff (Max) 15nA
Vce Saturation (Max) @ Ib, Ic 500mV @ 5mA, 100mA
Voltage - Collector Emitter Breakdown (Max) 25V
Current - Collector (Ic) (Max) 100mA
Frequency - Transition 130MHz
