BC239BBU
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 180 @ 2mA 5V 15nA 500mW 250MHz
PDF
/
Inventory: 954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 120
Emitter Base Voltage (VEBO) 5V
Collector Emitter Breakdown Voltage 25V
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 2mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 25V
Transistor Type NPN
Gain Bandwidth Product 250MHz
Power Dissipation 500mW
Element Configuration Single
Number of Elements 1
Base Part Number BC239
Frequency 250MHz
Current Rating 100mA
Max Power Dissipation 500mW
Voltage - Rated DC 25V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
