BC238BBU
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 25V 0.1A TO-92
PDF
/
Buying Options
Total Price: USD $9.1
Unit Price: USD $9.0953
≥1 USD $9.0953
≥10 USD $7.46225
≥100 USD $7.2295
≥500 USD $6.9958
≥1000 USD $6.76305
Inventory: 12404
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Continuous Collector Current 100mA
hFE Min 120
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 30V
Collector Emitter Saturation Voltage 25V
Collector Emitter Breakdown Voltage 25V
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 2mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 25V
Transistor Type NPN
Gain Bandwidth Product 250MHz
Power Dissipation 500mW
Element Configuration Single
Number of Elements 1
Base Part Number BC238
Frequency 250MHz
Current Rating 100mA
Max Power Dissipation 500mW
Voltage - Rated DC 25V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
