BC238A_J35Z

ON Semiconductor
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description Bulk Through Hole NPN BC238 Bipolar (BJT) Transistor 120 @ 2mA 5V 100mA 500mW 250MHz
PDF
/
Inventory: 9315
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Frequency - Transition 250MHz
Current - Collector (Ic) (Max) 100mA
Voltage - Collector Emitter Breakdown (Max) 25V
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 2mA 5V
Transistor Type NPN
Power - Max 500mW
Base Part Number BC238
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature 150°C TJ

Physical

Supplier Device Package TO-92-3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
