BC213
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP BC213 Bipolar (BJT) Transistor 80 @ 2mA 5V 500mA 625mW 200MHz
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.098962
≥1 USD $0.098962
≥10 USD $0.09336
≥100 USD $0.088076
≥500 USD $0.08309
≥1000 USD $0.078389
Inventory: 1217
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 80
Emitter Base Voltage (VEBO) -5V
Collector Base Voltage (VCBO) -45V
Frequency - Transition 200MHz
Current - Collector (Ic) (Max) 500mA
Voltage - Collector Emitter Breakdown (Max) 30V
Collector Emitter Breakdown Voltage 30V
Vce Saturation (Max) @ Ib, Ic 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 80 @ 2mA 5V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 600mV
Transistor Type PNP
Power - Max 625mW
Power Dissipation 625mW
Polarity PNP
Base Part Number BC213
Current Rating -500mA
Max Power Dissipation 625mW
Voltage - Rated DC -30V
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Physical
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
