2SC4614T-AN
RoHS
/
Package SC-71
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Through Hole NPN Single Bipolar (BJT) Transistor 100 @ 100mA 5V 1muA ICBO 1W 120MHz
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.980158
≥1 USD $0.980158
≥10 USD $0.924676
≥100 USD $0.872335
≥500 USD $0.822956
≥1000 USD $0.776377
Inventory: 3610
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case SC-71
Number of Pins 3
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2012
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Copper/Silver/Nickel (Sn/Cu/Ag/Ni)
Max Power Dissipation 1W
Frequency 120MHz
Pin Count 3
Number of Elements 1
Element Configuration Single
Power Dissipation 1W
Gain Bandwidth Product 120MHz
Transistor Type NPN
Collector Emitter Voltage (VCEO) 160V
Max Collector Current 1.5A
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 5V
Current - Collector Cutoff (Max) 1μA ICBO
Vce Saturation (Max) @ Ib, Ic 450mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 160V
Collector Emitter Saturation Voltage -200mV
Collector Base Voltage (VCBO) 180V
Emitter Base Voltage (VEBO) 6V
hFE Min 100
Dimensions
Height 4.5mm
Length 6.9mm
Width 2.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
