2SC4081RT1G
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 180 @ 2mA 6V 100nA 200mW 60V
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.03373
≥1 USD $0.03373
≥10 USD $0.031821
≥100 USD $0.030018
≥500 USD $0.028317
≥1000 USD $0.026722
Inventory: 1323
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
HTS Code 8541.21.00.95
Subcategory Other Transistors
Voltage - Rated DC 50V
Max Power Dissipation 200mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 100mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 2SC4081
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Transistor Application AMPLIFIER
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 500mV
Max Collector Current 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 2mA 6V
Current - Collector Cutoff (Max) 100nA
Vce Saturation (Max) @ Ib, Ic 500mV @ 10mA, 100mA
Collector Emitter Breakdown Voltage 50V
Collector Emitter Saturation Voltage 500mV
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 7V
hFE Min 180
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
