2N6427G
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN - Darlington Single Bipolar (BJT) Transistor 20000 @ 100mA 5V 500mA 625mW 130MHz
PDF
/
Inventory: 9757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
Physical
Contact Plating Copper, Silver, Tin
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Surface Mount NO
Number of Pins 3
Weight 4.535924g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2007
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Other Transistors
Voltage - Rated DC 40V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Current Rating 500mA
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 2N6427
Pin Count 3
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 625mW
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 40V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 20000 @ 100mA 5V
Current - Collector Cutoff (Max) 1μA
Vce Saturation (Max) @ Ib, Ic 1.5V @ 500μA, 500mA
Collector Emitter Breakdown Voltage 40V
Transition Frequency 130MHz
Collector Emitter Saturation Voltage 1.2V
Collector Base Voltage (VCBO) 40V
Emitter Base Voltage (VEBO) 12V
Continuous Collector Current 500mA
Dimensions
Height 6.35mm
Length 19.05mm
Width 6.35mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
