2N5401TAR
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 150V 0.6A TO-92
PDF
/
Inventory: 9657
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Voltage - Rated DC -160V
Max Power Dissipation 625mW
Current Rating -600mA
Frequency 400MHz
Base Part Number 2N5401
Number of Elements 1
Polarity PNP
Element Configuration Single
Power Dissipation 625mW
Power - Max 625mW
Gain Bandwidth Product 300MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) 500mV
Max Collector Current 600mA
DC Current Gain (hFE) (Min) @ Ic, Vce 60 @ 10mA 5V
Current - Collector Cutoff (Max) 50nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 5mA, 50mA
Collector Emitter Breakdown Voltage 150V
Voltage - Collector Emitter Breakdown (Max) 150V
Current - Collector (Ic) (Max) 600mA
Frequency - Transition 400MHz
Collector Base Voltage (VCBO) -160V
Emitter Base Voltage (VEBO) -5V
hFE Min 60
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Box (TB)
Operating Temperature -55°C~150°C TJ
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Weight 178.2mg
Supplier Device Package TO-92-3
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
