2N4403RLG
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 40V 0.6A TO-92
PDF
/
Inventory: 3448
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Turn Off Time-Max (toff) 255ns
hFE Min 30
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 40V
Collector Emitter Saturation Voltage 750mV
Transition Frequency 200MHz
Current - Collector (Ic) (Max) 600mA
Collector Emitter Breakdown Voltage 40V
Vce Saturation (Max) @ Ib, Ic 750mV @ 50mA, 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 2V
Max Collector Current 600mA
Collector Emitter Voltage (VCEO) 750mV
Transistor Type PNP
Polarity/Channel Type PNP
Gain Bandwidth Product 200MHz
Transistor Application SWITCHING
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number 2N4403
Time@Peak Reflow Temperature-Max (s) 40
Current Rating -600mA
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC -40V
Subcategory Other Transistors
HTS Code 8541.21.00.75
Additional Feature EUROPEAN PART NUMBER
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
