2N4402TF
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Through Hole PNP Single Bipolar (BJT) Transistor 50 @ 150mA 2V -600mA 625mW 40V
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 1297
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 240mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -40V
Max Power Dissipation 625mW
Current Rating -600mA
Base Part Number 2N4402
Number of Elements 1
Element Configuration Single
Power Dissipation 625mW
Transistor Type PNP
Collector Emitter Voltage (VCEO) 40V
Max Collector Current 600mA
DC Current Gain (hFE) (Min) @ Ic, Vce 50 @ 150mA 2V
Vce Saturation (Max) @ Ib, Ic 750mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 40V
Collector Emitter Saturation Voltage 750mV
Collector Base Voltage (VCBO) 40V
Emitter Base Voltage (VEBO) 5V
hFE Min 50
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
