2N3904CTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole NPN Single Bipolar (BJT) Transistor 100 @ 10mA 1V 200mA 625mW 300MHz
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 15121
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 178.2mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 40V
Max Power Dissipation 625mW
Current Rating 200mA
Frequency 300MHz
Base Part Number 2N3904
Number of Elements 1
Element Configuration Single
Power Dissipation 625mW
Gain Bandwidth Product 300MHz
Transistor Type NPN
Collector Emitter Voltage (VCEO) 40V
Max Collector Current 200mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 10mA 1V
Vce Saturation (Max) @ Ib, Ic 300mV @ 5mA, 50mA
Collector Emitter Breakdown Voltage 40V
Collector Emitter Saturation Voltage 300mV
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 6V
hFE Min 100
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
