2N3702
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 60 @ 50mA 5V 100nA ICBO 625mW 100MHz
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.0704
≥1 USD $0.0704
Inventory: 16536
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Subcategory Other Transistors
Voltage - Rated DC -25V
Max Power Dissipation 625mW
Terminal Position BOTTOM
Terminal Form WIRE
Reach Compliance Code unknown
Current Rating -500mA
Frequency 100MHz
Base Part Number 2N3702
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Power Dissipation 625mW
Gain Bandwidth Product 100MHz
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) -25V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 60 @ 50mA 5V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 250mV @ 5mA, 50mA
Collector Emitter Breakdown Voltage 25V
Transition Frequency 100MHz
Collector Base Voltage (VCBO) -40V
Emitter Base Voltage (VEBO) -5V
hFE Min 60
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
