BC328-40-AP
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole PNP SINGLE Bipolar (BJT) Transistor 250 @ 100mA 1V 800mA 625mW 260MHz
PDF
/
Inventory: 1392
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C
Packaging Tape & Box (TB)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code O-PBCY-W3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Power - Max 625mW
Polarity/Channel Type PNP
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 250 @ 100mA 1V
Current - Collector Cutoff (Max) 200nA
Vce Saturation (Max) @ Ib, Ic 700mV @ 50mA, 500mA
Voltage - Collector Emitter Breakdown (Max) 25V
Current - Collector (Ic) (Max) 800mA
Transition Frequency 260MHz
Frequency - Transition 260MHz
Compliance
RoHS Status RoHS Compliant
