B772-R-TP
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP DPAK
PDF
/
Inventory: 9149
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
Power - Max 1.25W
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 60 @ 1A 2V
Current - Collector Cutoff (Max) 10μA
Vce Saturation (Max) @ Ib, Ic 500mV @ 200mA, 2A
Voltage - Collector Emitter Breakdown (Max) 30V
Current - Collector (Ic) (Max) 3A
Frequency - Transition 50MHz
Compliance
RoHS Status RoHS Compliant
