2SB562-C-AP
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANSISTOR TO-92 MOD
PDF
/
Inventory: 3270
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Power - Max 900mW
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 120 @ 500mA 2V
Current - Collector Cutoff (Max) 1μA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 80mA, 800mA
Voltage - Collector Emitter Breakdown (Max) 20V
Current - Collector (Ic) (Max) 1A
Frequency - Transition 350MHz
Compliance
RoHS Status RoHS Compliant
