TIP35C
RoHS
/
Package TO-218-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN SINGLE Bipolar (BJT) Transistor 10 @ 15A 4V 25A 125W 3MHz
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.8568
≥1 USD $1.8568
≥10 USD $1.49453
≥100 USD $1.22965
≥500 USD $1.040486
≥1000 USD $0.882851
≥3000 USD $0.838702
Inventory: 1141
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Frequency - Transition 3MHz
Transition Frequency 300MHz
Current - Collector (Ic) (Max) 25A
Collector Emitter Breakdown Voltage 100V
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 15A 4V
Max Collector Current 25A
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Case Connection COLLECTOR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 125W
Subcategory Other Transistors
HTS Code 8541.29.00.75
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-218-3
Mounting Type Through Hole
Mount Through Hole
