TIP33A
RoHS
/
Package TO-218-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN SINGLE Bipolar (BJT) Transistor 100 @ 3A 4V 10A 80W 3MHz
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
Inventory: 1369
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Frequency - Transition 3MHz
Transition Frequency 3MHz
Current - Collector (Ic) (Max) 10A
Collector Emitter Breakdown Voltage 60V
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 3A 4V
Max Collector Current 10A
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Case Connection COLLECTOR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 80W
Subcategory Other Transistors
HTS Code 8541.29.00.95
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Operating Temperature -65°C~150°C TJ
Physical
Transistor Element Material SILICON
Package / Case TO-218-3
Mounting Type Through Hole
Mount Through Hole
