TIP30C PBFREE
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
THROUGH-HOLE TRANSISTOR-BIPOLAR
PDF
/
Inventory: 9028
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Technical
Operating Temperature -65°C~150°C TJ
Packaging Bulk
JESD-609 Code e3
Part Status Active
Terminal Finish MATTE TIN OVER NICKEL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Power - Max 30W
Transistor Type PNP
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 200mA 4V
Current - Collector Cutoff (Max) 300μA
Vce Saturation (Max) @ Ib, Ic 700mV @ 125mA, 1A
Voltage - Collector Emitter Breakdown (Max) 100V
Current - Collector (Ic) (Max) 1A
Frequency - Transition 3MHz
Compliance
RoHS Status ROHS3 Compliant
