TIP2955
RoHS
/
Package TO-218-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP SINGLE Bipolar (BJT) Transistor 20 @ 4A 4V 15A 90W 3MHz
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.1352
≥1 USD $1.1352
≥10 USD $0.90963
≥100 USD $0.72087
≥500 USD $0.610993
≥1000 USD $0.497719
≥3000 USD $0.468538
Inventory: 330
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-218-3
Transistor Element Material SILICON
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.29.00.95
Subcategory Other Transistors
Max Power Dissipation 90W
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Case Connection COLLECTOR
Transistor Application AMPLIFIER
Polarity/Channel Type PNP
Transistor Type PNP
Max Collector Current 15A
DC Current Gain (hFE) (Min) @ Ic, Vce 20 @ 4A 4V
Collector Emitter Breakdown Voltage 100V
Current - Collector (Ic) (Max) 15A
Transition Frequency 3MHz
Frequency - Transition 3MHz
Compliance
RoHS Status Non-RoHS Compliant
